APC EMUPS50K250QBHS
Easy UPS 3-Phase Modular 50kW Scalable to 250kW 400V Black, 1 Switch, for Ext Batt, Start-up 5×8
Presentation
EMUPS50K250QBHS : The Easy UPS 3-Phase Modular uninterruptible power supply is a robust, modular, high-density 50 kW, 400V 3-phase UPS that is scalable up to 250 kW N+1. It delivers high availability, scalability, and redundancy in a compact footprint in a cost-optimized, EcoStruxure connected package ideal for small and medium data centers and other business-critical applications. Includes 5×8 start-up service and 1 switch.
Lead Time
- Usually ships within 2 weeks
Main Specifications
- Main Input Voltage: 400 V
- Other Input Voltage: 400 V
- Main Output Voltage: 400 V
- Other Output Voltage: 400 V
- Rated Power in W: 50 kW
- Rated Power in VA: 50 kVA
- Battery Type: VRLA
- Provided Equipment: User manual, Dust filter, Network management card, Start-up service
- Range of Product: Easy UPS 3-Phase Modular
- Range Compatibility: Easy UPS 3-Phase Modular
Batteries & Runtime
- Battery Voltage: 480…576 V DC
- Max Current Discharge: 130 A
General
- Bypass Voltage Tolerance: +/- 10%
- Max Bypass Input Current: 74 A
- Number of Power Modules: 1
- Number of Power Module Free Slots: 5
- Redundant: Yes
- Product or Component Type: Uninterruptible power supply (UPS)
Physical Specifications
- Colour: Black
- Dimensions: 199.1 cm (H) x 60 cm (W) x 85 cm (D)
- Net Weight: 251 kg
- USB Compatible: Yes
Input
- Network Frequency: 40…70 Hz
- Maximum Input Current: 95 A
- Max Short Time Withstand Current: 35 kA
- Input Harmonic Distortion: Less than 3% for full load
- Load Power Factor: From 0.7 leading to 0.7 lagging without any derating
Output
- Maximum Configurable Power in W: 250 kW
- Output Frequency: 50…60 Hz
- UPS Type: Double conversion online
- Maximum Configurable Power in VA: 250 kVA
Conformance
- Standards: IEC 62040-1 safety, IEC 62040-2, IEC 62040-3, IEC 61641
Environmental Specifications
- Operating Temperature: 0…40 °C
- Relative Humidity: 0…95% non-condensing
- Operating Altitude: 0…3000 m
- Storage Temperature: -25…55 °C
- Storage Relative Humidity: 0…95% non-condensing
- Acoustic Level: 74 dB
- Heat Dissipation: 8414 Btu/h
- IP Degree of Protection: IP20
Packing Units
- Package Type: PCE
- Package Height: 219.1 cm
- Package Width: 120 cm
- Package Length: 80 cm
- Package Weight: 262 kg
- Number of Units in Package: 1
